Fixing PNG Issues on 64x16 Displays: A RAW RGB Workaround

Hey everyone! Having trouble getting those PNG images to display correctly on your 64x16 device? You're not alone! It seems like some users, like lucagoc, have run into a snag where standard PNG files just don't want to cooperate. In this article, we will explore the issue of PNG incompatibility on 64x16 displays and how to use RAW RGB as an alternative.

The PNG Problem on 64x16 Devices

The main keyword here is PNG incompatibility. Imagine you've created a beautiful image in GIMP, saved it as a PNG, and you're ready to showcase it on your 64x16 display. But, alas, nothing shows up! This can be super frustrating, especially when you've spent time crafting the perfect visual. The issue, as lucagoc pointed out, is that the device might not be playing nicely with PNG files in the way we expect. This could be due to a variety of reasons, such as the specific PNG encoding, memory limitations on the device, or even firmware quirks. Understanding the root cause can be a bit technical, but the important thing is that we need a solution! When dealing with such limitations, RAW RGB data emerges as a robust alternative, bypassing the complexities of PNG encoding and offering a direct pathway to display images.

Diving Deeper into PNG Compatibility

Let's delve a bit deeper into why PNG files might be causing headaches. PNG, or Portable Network Graphics, is a popular image format known for its lossless compression. This means it can compress images without losing any of the original data, making it great for detailed graphics and images with text. However, the very compression that makes PNG so efficient can also be its downfall in certain situations. Decoding a PNG file requires processing power and memory. On a 64x16 device, which may have limited resources compared to a modern computer, this decoding process can become a bottleneck. The device might simply not have enough horsepower to decompress the PNG in real-time, leading to display issues. Another factor to consider is the specific type of PNG encoding used. PNG supports various encoding methods, and some might be more resource-intensive than others. If the PNG was saved with a complex encoding scheme, it could further strain the device's capabilities. Finally, there's the possibility of firmware-level incompatibilities. The device's firmware is the software that controls its basic operations, and if it doesn't have proper support for PNG decoding, you're going to run into problems. It's like trying to play a Blu-ray disc on a DVD player – the hardware just isn't designed to handle the format.

Why RAW RGB is a Solid Alternative

So, if PNG is giving us grief, why is RAW RGB the hero we need? The key is in the name: RAW. Unlike PNG, which is a compressed format, RAW RGB data is uncompressed. It's the bare bones representation of the image, where each pixel's color is defined by its red, green, and blue components. Think of it like this: PNG is like a neatly packaged gift, while RAW RGB is like the individual components laid out on the table. While the packaged gift (PNG) is convenient, you need the right tools to unwrap it. The individual components (RAW RGB), on the other hand, are immediately accessible. Because RAW RGB is uncompressed, the device doesn't need to perform any complex decoding. It simply takes the RGB values and displays them directly. This makes it much less demanding on the device's resources. The trade-off, of course, is file size. RAW RGB files are significantly larger than their PNG counterparts because they contain all the pixel data without any compression. However, on a 64x16 display, the image size is relatively small to begin with, so the increased file size is often a worthwhile compromise for the sake of compatibility and performance.

Enter RAW RGB: A Workaround

Now, let's talk about the workaround: using RAW RGB data. As lucagoc discovered, sending RAW data directly to the device works perfectly. This is because RAW RGB is a much simpler format for the device to process, bypassing the complexities of PNG decoding. It's like speaking the device's native language! But how do we actually create this RAW RGB data? That's where ImageMagick comes in.

How to Create RAW RGB Data with ImageMagick

ImageMagick is a powerful command-line tool for image manipulation. It's like a Swiss Army knife for image processing, and it's exactly what we need to convert our PNG images into RAW RGB format. The magic happens with the stream command. Here's the command lucagoc shared:

stream -map rgb -storage-type char image.png image.raw

Let's break down what this command does:

  • stream: This is the ImageMagick command we're using to process the image data.
  • -map rgb: This tells ImageMagick to extract the red, green, and blue color channels from the image.
  • -storage-type char: This specifies that we want to store the color values as characters (bytes), which is the format RAW RGB typically uses.
  • image.png: This is the input PNG file you want to convert.
  • image.raw: This is the output file where the RAW RGB data will be saved. You can name this whatever you like, but the .raw extension is a common convention.

So, in a nutshell, this command takes your PNG image, extracts the RGB color data for each pixel, and saves it in a simple, uncompressed .raw file. This .raw file is what we'll then send to our 64x16 device.

Patching send_png for RAW Support

Now, here's where things get even more interesting. lucagoc went a step further and provided a patch to the send_png function. This patch allows the function to directly handle .raw files, making the whole process even smoother. Let's take a look at the patch:

diff --git a/commands.py b/commands.py
index 936abdc..5fe83ec 100644
--- a/commands.py
+++ b/commands.py
@@ -266,7 +266,7 @@ def send_text(text, rainbow_mode=0, animation=0, save_slot=1, speed=80, color="f

 def send_png(path_or_hex):
     """Send a PNG image to the device."""
-    if path_or_hex.endswith(".png"):
+    if path_or_hex.endswith((".png",".data",".raw")):
         with open(path_or_hex, "rb") as f:
             png_hex = f.read().hex()
     else:

This patch modifies the send_png function to check if the file path ends with .png, .data, or .raw. If it does, it opens the file, reads its contents as hexadecimal data, and sends it to the device. This is a simple but effective way to add RAW RGB support without having to create a separate function. By including .data as a supported extension, the patch shows foresight in accommodating various potential file types or naming conventions that users might employ. This flexibility enhances the tool's usability, ensuring that it can adapt to different workflows and user preferences.

Applying the Patch

If you're comfortable with patching code, applying this patch is a great way to streamline your workflow. The patch essentially tells your system to replace a specific line of code in the commands.py file with a modified version. There are various ways to apply patches, but a common method involves using the patch command in a terminal. You'd typically save the patch as a .diff file and then run a command like patch < your_patch_file.diff in the directory containing commands.py. However, if you're not familiar with patching, don't worry! You can simply open the commands.py file in a text editor and manually make the changes. Just find the line if path_or_hex.endswith(".png"): and replace it with if path_or_hex.endswith((".png",".data",".raw")):.

Using the Modified send_png Function

With the patch applied (or the code manually modified), you can now use the send_png function to send your RAW RGB images directly! This makes the process super convenient. Instead of having to use a separate command or function for RAW data, you can use the same familiar send_png command. It's all about making things easier and more efficient. The beauty of this approach lies in its simplicity. By integrating RAW RGB support directly into the send_png function, the user experience is significantly improved. You no longer need to remember different commands for different image formats; the function intelligently handles both PNG and RAW RGB files. This reduces the cognitive load on the user and makes the tool more accessible to a wider audience.

Conclusion: RAW to the Rescue!

So, there you have it! If you're struggling to display PNG images on your 64x16 device, don't despair. RAW RGB data is a fantastic alternative that can get your images up and running. By using ImageMagick to convert your PNGs to RAW and applying the provided patch, you can seamlessly send images to your device. This workaround not only solves the immediate problem of PNG incompatibility but also highlights the importance of understanding different image formats and their suitability for specific applications. When we encounter limitations with one format, exploring alternatives like RAW RGB can open up new possibilities and ensure that our creative visions are realized. Remember, the world of digital displays is full of interesting challenges, and sometimes the simplest solutions, like using RAW data, are the most effective! Happy displaying, guys!
